AM-CB011
Amber
AM-CB011
Laminar Flow Hood is a clean equipment that transports indoor air through the air filtration system, through the HEPA filter, and then into the operation area in a unidirectional laminar flow. Effectively isolate the operation area and the external environment of the cross-contamination, to protect the samples, equipment and operator safety.
Laminar Bench is the core equipment to ensure the cleanliness of the air in the operation area. According to the different airflow directions, Laminar Bench can be divided into Vertical Laminar Bench and Horizontal Laminar Bench.
When purchasing a Laminar Bench, many customers are confused as to which is more suitable, vertical or horizontal.
Vertical Clean Bench: Air flows from top to bottom, suitable for microbiology, cell culture, sterile drug dispensing and other operations that require high sample protection.
Horizontal Laminar Flow: Air is blown from back to front, more suitable for electronic component assembly, optical testing, precision instrumentation operations, and protects operators with lower risk of exposure.
If your work mainly involves biopharmaceuticals, scientific research and testing, the vertical laminar flow type may be more suitable.
1. 99.99% filtration efficiency, can effectively intercept particles ≥ 0.3μm.
2. Equipped with a silent fan system to ensure cleanliness while reducing noise, it will provide a good and comfortable experience even when operating for a long time.
3. LED energy-saving lighting system, soft and even light without dead angle, easy to operate in detail.
4. Support customisation, including material, size and other parameters.
| Model | VFCB-1000 one position | VFCB-1500 two position |
| Outer size mm | 1000*650*1800 | 1500*650*1800 |
| Work area size mm | 900*600*600 | 1400*600*600 |
| Cleanliness | Class 100 ISO 14644-1 | |
| Air flow | 900m³/h | 1500m³/h |
| Air flow speed | 0.45±20% | |
| HEPA filter size | 880*570*69*1 | 760*570*69*2 |
| Filtering efficiency | 99.99%@0.3μm | |
| LED light power | 20W*1 | 40W*1 |
| Fan power | 190W | 270W |
| Noise | ＜65dB | |
| Voltage / Power | AC 220V/50HZ | |
